50m Polygonal Q345B Lightning Protection Tower

Polygonal Good Quality Customizable Lightning Protection System Tower

Feautures:

Specification
Lightning Rod Protection Tower
Beautiful appearance. Communication network construction must be
used. Adopt hot dip galvanizing anticorrosion treatment, the
direction of communication equipment can be adjusted. In addition
to man-made damage and rare natural disasters will never lose its
function.
Early discharge time:

Size of Lightning ArresterEarly discharge time
3.3>25μs
4.3>34μs
5.3>43μs
6.3>52μs

Maxium radius of protection:

Lightning protection radius
Building height(m)3.34.35.36.3
First kind of lightning protection building45m54m63m70m
Second kind of lightning protection building65m74m84m92m
Third kind of lightning protection building75m85m95m102m

Type
Straight Pole ,Suspension Pole ,Turn Pole, Terminal Pole,
Suit for
Pole For Lightning Protection
Shape
Multi-pyramidal,Columniform, Round, Polygonal (Octagonal,
Dodecagonal, Hexadecagonal, etc)
Material
Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400,
SS490ST52, and others equivalent steel material
Power
10 KV ~220 KV
Safety Factor
Safety factor for conducting wine : 8
Safety factor for grounding wine : 8
Standard
ISO 9001:2008
Surface treatment
Hot dip galvanized Following ASTM A 123, color polyester power or
any other standard by client required.
Joint of Poles
Slip joint , flange connected
Wall Thickness
2~30mm
Height
From 9 meter to 100 meter
Length of per section
Within 14m once forming without slip joint.
Welding
flaw testing.Internal and external double welding makes the welding
good
Welding Standard :AWS ( American Welding Society ) D 1.1
Bolts and Nuts
Mainly ISO 898 grade 6.8 and 8.8 bolts for Both Chinese, ISO and
DIN standard
Base plate
Base plate is square/round/Polygon with slotted holes for anchor
bolt and dimension as per client's requirement.
Marks
Nane palte through rivert or glue ,engrave ,emboss as per customer
requirement
Production Process
Rew material test → Cutting →bending →Welding (longitudinal
)→Dimension verify →Flange welding →Hole drilling →Calibration →
Deburr→Galvanization or powder coating ,painting →Recalibration
→Thread →Packages→Delivery

Product Show

Our Company

Hebei ChangTong steel tower Co., Ltd. located in the hometown of China Tower, is a modern big-scale professional company fabricating triangular communicationtower,four-corner communication tower, cable tower, single-tube tower,camouflage communication tower and transmission line tower.integrating design,fabrication and marketing,annual
production capacity reaches more than 30,000 tons.
